FD-911SA 100KW Electron Tube Triode High power triode

Description: FD-911SA 100KW Electron Tube Triode High power triode
INQUIRY EMAIL

FD-911SA-type Electron Tubes are ceramic triodes, with their anodes cooled by water, and their maximum anode dissipation powers at 80kW; when at a frequency not higher than 26MHz, their output powers may attain to 100kW. They are mainly applied in industrial high-frequency heating equipments for oscillations or in radio equipments for amplifications.

Ceramic-metal triodes (5-350KW)
Type			FD-911SA
Equivalent on abroad
Output power(KW)			100
Cathode	Cathode materials		Thoriated Tungsten
	Voltage(V)		12
	Current(A)		210
Main electric parameters	Amplification factor		33
	Inter-electrode Capacitances (PF) (Cathode earthed)	Filament-Grid	100
		Filament-Anode	2
		Anode-Grid	77
Maximum	Maximum anode dissipation (KW)		80
	Maximum grid dissipation (W)		2600
	Maximum anode DC voltage (KV)		15
	Maximum frequency (MHz)		26
Cooling			S
Weight (kg)			16
Additional: The information here may be modified with the products variation. Cooling: F--Forced air cooling S--Water cooling Z--Vapor cooling
